Parallel screw and barrel

Price: 500.0~30000.0 USD
Payment Terms: T/T,WU
Place of Origin: Zhejiang, China (Mainland)
inquire skype
Add to My Favorites
HiSupplier Escrow
Share |

Product Detail

Model No.: HC-P108
Production Capacity: 2000 ets
Delivery Date: 25-30 days
Brand Name: HUACHEN
Treatment: Nitriding and bimetallic
Apply for: PVC PE PP... ,PVC+GF,CaCo3
Final product: Profile,sheet,board,pelletz...
Technology: CNC Machines
Means of Transport: Ocean,Air
Packing: AA grade worden Case
Plastic Type: PVC
Material: 38CrMoAlA,SACM645,42CrMo
Bimetallic layer: add 5%-45% Tungsten Carbide
Machine: Parellel screw extruder mac...
Machine Brand: Battenfeld,KMD,CINCINATI,WE...
Specification: Φ15-Φ105 for China extruder...

1.Apply to Battenfeld Cincinati Weber KMD
2.Certificate:ISO9001:2008
3.End products:WPC,proflie, pipe film etc.

Technical Parameters:
sheet 1
Materials of Parallel twin screw and barrel
Base Materials
1)38CrMoAlA(JIS SACM645) 2)Cr12MOV(JIS SKD-11)
3)4Cr5MoSiV1(JIS SKD-61)4)42CrMo(AISI 4140)
Bimetallic
1)Fe-based alloy 2)Ni-based alloy
3)Co-based alloy 4)NiCo-based alloy
5)Tungsten carbide/Wolfram carbide
Tungsten Carbide
Level A - containing Tungsten of 40%
Level B - containing tungsten of 25%
Level C - containing tungsten of9.5%

Sheet 2
Plastic material application
Plstic material application
1)General Plastics
2)ABS,PA,PC,PE,PET,PP,PS,EVA,PU,PVC,U-PVC,etc
3)PA + GF(Glass Fiber)
4)Flame-resistant Reinforced Plastics
5)Modified Engineering Plastics
6)All kinds of Mixed Recycled Material(in Scrap orGranule),etc

Sheet 3
Surface Treatment
Heat Treatment
High Frequency Treatment
Nitriding treatment(120 Hours)
Depth of Nitrided Layer: 0.5-0.8 mm
Hardness of Nitrided Layer: 900-1020Hv(HRC56°-65°)
Hard Chrome Plating treatment
Thickness of Hard Chrome Plating Layer: 0.05-0.10mm
Hardness of Hard Chrome Plating Layer: ≥950HV
Bimetallic treatment
Bimetallic Barrel/Cylinder: Centrifugal Casting (InlayAlloy)
Bimetallic Screw: Plasma Alloy Coating Spraying
Depth of Bimetallic Layer: >2mm
Hardness of Bimetallic Layer:HRC55°-72°













sheet4
Basic information
Roughness of the surfaceRa0.4um
Linearity of the screw≤0.015mm
Linear axis limit≤0.02mm
Hardness after Hardening & TemperingHB240-280
Fragility of Nitration≤Two class

Basic Alloy Steel Material We use:
Normal Material we use as following:
1.38CrMoAlA(JIS SACM645),
2.Cr12MOV(JIS SKD-11)
3.4Cr5MoSiV1(JIS SKD-61)
4.42CrMo(AISI 4140)
The foreign material we used as following:
1. Germanysteel, GH113 ,2250 ,2842 ,1.8509 ,1.442 ,1.6582 ,1.6523 ,1.2080,1.4542,
2. USA steel, P20,420,L6,H13,W110,D3,A2,D6,O1,S1,M35,8620,3115,K52440
3. Sweden steel, 718S,718H,S136,S136H,STAVAX,ASP-23,ASP-30
4. Australia Steel, M202,M300,W302,K460,W300,K900,K100,W321
5. Hardnesssteel, YG6X,YG 6A,YG 6,YG8N,YG8,YG8C,YG11C,YG 15,YT5,YT14,YT30
6. Japan Steel, SKT 4,YXM 4,YXM 42,SNC 815,SK -3,SKS 3,and etc.

Production steps:

CustomeOrder--Product Design(Customer Drawing)—Production FlowArrangement—Material Procurement—Hardening&Tempering—Drilling—RoughTurning—Rough Thread Rolling(Alloy Spray Welding)—Alignment—FineThreadRolling—Mixing—Alignment—High FrequencyTreatment—Alignment—Polishing—Grinding—120 Hours NitridingTreatment—AcidPiclking—Polishing—Chrome Plating—O.D.Grinding—Packaging&Shipping

Processing
Parallel twin screw barrel for PVC Pipe apply to Weber Cincinati Battenfeld

Advantages of Parallel twin screw:

--Good plasticization, high productivity, small shear force,stable pressure,less wear and tear and low cost.
--Good at feeding,especially for powder.And also have the superiority inhot temperature-unstability plastic materials and mixture palsticmaterials.

Application of Parallel twin screws:
Parallel twin-screw and barrel is successfully applied in PVCplate,pipe,profile,pellet and so on,at the same time, it solved thetechnical problem of low foaming,high foaming,high filling, wear andcorrosion.

Compare to single screw barrel,
It is better than single screw barrel in the followings: mix turematerials,exhausting,self-cleaning.

Compare to conical twin screw,
Parallel twin-screw and barrel is widely used in PVC productsprocessing,especially for the production of PVCproducts with the outputover 350Kg /h, because the parallel twin-screw and barrel costs lessthan conical twin-screw and barrel while it has more maturer technology.

Materials and products:
Parallel twin screw barrel for PVC Pipe apply to Weber Cincinati Battenfeld

Our Quality Control:

We strictly control our quality as the ISO 9001:2008. We test our products from the raw materials to final product.

Quality is our main forte and we followvaried industry policies for achieving it. Furthermore,our qualityconsciousness has ensured that wemanufacture premium qualityScrew & Barrel for the clients. We conduct various quality tests onour range that start from the time of procuring raw material till thefinal supply of products. Apart from this,our quality controllerscontinuously check the entire range on different parameters soas toensure its defect-free nature.Our quality testing laboratory iswell-equipped with modern machines and technology that are necessary forbulk production.

Our certificate of ISO 9001:2008
Weber Cincinati Battenfeld parallel twin screws barrel for PVC pipe buckle
Product show:






Weber Cincinati Battenfeld parallel twin screws barrel for PVC pipe buckle
About HUACHEN :
Our Strength: We have an experience ofmore than 20 year of manufacturing and designing Plastic machines,varied Screws and Barrels and spares.  We concentrate on improvingquality,updating design and enhancing service.
Our products:Screws Barrels for Injection, Extrusion, and Blow Molding applications; relevant accessories(such as die head, gearbox, filter screen changer and so on); plastic processing  machinery.
Location advantage: Near Ningbo/Shanghai Port.
Market areas: global sales network reaching South America, Eastern Europe, Southeast Asia, Africa, Oceania and the Mid-East
We promise: We assure the customer benefits, provide competitive price, emphasis On Cooperation.

HUACHEN COMPANY
Bimetallic parallel twin screws and barrel for PVC Caco3 pipe

Please contact us,if you have any questions. Mail,phone,skype all are OK.
Myskype:lillianyao0421
Ms. Emilie Zhang
skype Ms. Emilie Zhang
Manager
Tel: 86-580-8052288
Fax: 86-580-8053878
Mobile: 139 6723 6330
